54733-10BA2L
3 – 372 02.2017
Menu Structure Volume 3
7 HV Live Displays the current HV (high voltage) at the photomultiplier. If
HV Mode is set to AUTO (normal operation), the values in HV
Live must change, viewed over several seconds.
8 Cps Single Detector Display of the count rate of each master or slave detector.
9 Cps Live Displays the current total count rate of all detectors.
2.43 Plateau View
Menu path: Device Config Setup Service Plateau
Plateau View.
This menu allows you to display the plateau data in a table or as a
plateau curve.
1 Active Detector No. Choose the detector for which you want to display the plateau val-
ues.
• Detector No. = 0 shows the plateau values of the master
detector.
• Detector No. = 1 shows the plateau values of slave 1.
•etc.
2 Refresh Plateau Updates the plateau table by loading the data from the detector.
3 Plateau Table Shows the plateau data points in a table.
4 Plateau Curve Shows the plateau data points in a curve.
2.44 Plateau Information
Menu path: Device Config Setup Service Plateau
Plateau Information.
General information on the plateau measurement.
1 Active Detector No. Choose the detector for which you want to display the plateau
values.
• Detector No. = 0 shows the plateau values of the master
detector.
• Detector No. = 1 shows the plateau values of slave 1.
•etc.
2 Plateau Date Shows the date of the last plateau recording.
No plateau recording exists, if the date 01/01/2000 is displayed.
3 Plateau Tab Entries Displays the number of data points for the plateau measurement.
