54733-10BA2L
2 – 164 02.2017
1 System Description Volume 2
Cable cross-section The cable cross-section is dependent on the cable glands used.
Wire cross-section for spring-type
terminals
0.5mm
2
to 2.5mm
2
; stripped length 10mm
Scintillators
High voltage generation
Voltage range of control 300V to 1300V
(error message below 300V and above 1300V)
Voltage range external setting 300V to 1300V
Sensitivity changes due to temperature variation or due to ageing
are automatically compensated for by an automatic high voltage
control.
Counter Rate max. 1,000,000 cps
Automatic decay compensation For Cs-137, Co-60 and a universally configurable isotope
Type Scintillator Dose Rate (typic)
for CS-137 in μSv/h
for 1000 lps
Tem p er a -
ture stabil-
ity
Weight in kg Weight in kg
with water cool-
ing
CrystalSENS
(Point detector)
NaI (Tl) 50*50mm
NaI (Tl) 40*35mm
NaI (Tl) 25*25mm
NaI (Tl) 44*5mm
0,8µSv/h
1,6µSv/h
5,4µSv/h
(Am-241)
≤0.002%/° C 11 (w/o collim.)
20.5 (with col-
lim.)
14.5 (w/o collim.)
24 (with collim.)
UniSENS
(Rod detector)
Polymer
scintillator
500mm
0,17µSv/h ≤0.01%/° C 14 21
Polymer
scintillator
1000mm
0,09µSv/h 18 28
Polymer
scintillator
1500mm
0,06µSv/h 22 35.5
Polymer
scintillator
2000mm
0,04µSv/h 27 44
TowerSENS
(Rod detector)
Polymer
scintillator
1000mm
0,1-0,15µSv/h
pro m
≤0.02%/° C 27 -
Polymer
scintillator
2000mm
≤0.02%/° C 41 -
SuperSENS
(Point detector)
Polymer
scintillator
150*150mm
Cs-137: 0,14µSv/h
Co-60: 0,2µSv/h
≤0.01%/° C 60 61
