54733-10BA2L
2 – 174 02.2017
2 Installation Volume 2
2.1.3 Temporary Storage of Sources
The operator has to take suitable provisions for temporary storage
of sources at the place of installation between the period from
source delivery to the start of the installation work.
Sources will be stored in their shieldings. A source may be stored
only in a lockable room which is identified accordingly. Accessible
controlled areas have to be identified and, if necessary, secured.
2.1.4 Installation Sites
Risk of injury!
Heavy system parts may fall down if not installed properly.
The bearing capacity of the vessel walls or the brackets must be
suitable for installation of the source with the shielding and the
detector.
Free space must be foreseen at the installation site for:
• Freedom of motion for delivery of shielding, detector and eval-
uation unit.
• The electrical installation of the detector.
• Servicing and repair work, to install and dismantle parts.
The fixture for the assembled system components must not trans-
fer any vibrations to the detector or the shielding. Likewise, it has
to be ruled out that too high temperatures can be transferred to the
system components.
The source with shielding and the detector are horizontally installed
on the designated position on the outside of the vessel and outside
a possibly installed heat insulation. The exact position for your sys-
tem parts is stated on the calculation documents and the technical
information prepared by BERTHOLD TECHNOLOGIES.
2.1.5 Unpacking and Cleaning System Parts
After unpacking, compare all parts with the packing list and check
if the shipment is complete and shows any sign of damage. If nec-
essary, you may have to clean parts.
If you detect any damage, notify the forwarder and the manufac-
turer immediately.
