54733-10BA2L
2 – 196 02.2017
2 Installation Volume 2
Open shielding
After the shielding has been installed, it may be opened only for
commissioning. Open the transportation safety device and open
the lock. Now use the lever fixed to the base with adhesive tapes
and plug it into the borehole for the locking mechanism. Open the
beam channel by turning the lever to the right up to the right limit
stop.
This position can now be locked again with the padlock to prevent
inadvertent closing of the beam channel during operation. If lock-
ing with the lock should not be permitted, you may also fix the
position with the supplied screws.
Pneumatic actuator Point source shieldings may as an option be supplied with a pneu-
matic actuator. You find the technical data in chapter 5.
Risk of crushing!
The cylinder rotates automatically! Fingers may get jammed on the
strap or on the locking piece.
Never change the factory-adjusted setting for attenuation on the
pneumatic actuator. This pre-setting ensures that the cylinder
rotates slowly and the risk of crushing is low.
