54733-10BA2L
3 – 358 02.2017
Menu Structure Volume 3
• RAD. INTERFERENCE
The alarm is triggered when interference radiation is detected. The
function can be selected only if you have selected RAD.
INTERFERENCE at Response Mode (Device Config Setup
Signal Condition Radiation Interference Response Mode,
page 3-331).
The alarm for RAD. INTERFERENCE is output even when you
select WARNING + ERROR.
2 Digital Out State Displays the current value of the digital output. If the test mode is
active, then the test value is displayed. The following functions can
be displayed:
– Normal
– Alarm
3 Level Threshold Settings Opens the menu in which the limit value for the alarm output can
be set (page 3-359).
4 Temp. Threshold Settings Opens the menu for the temperature-related settings (page 3-
360).
