54733-10BA2L
3 – 392 02.2017
4 Quick Guide to Calibration Volume 3
Step 3 - Calibration Points At the CrystalSENS you can skip the following item Background,
unless the measurement is safety-relevant.
Background
The source shielding is not mounted at the measuring point, but at
least it is adequately shielded (see chapter 7.1, page 3-411).
Select ReadIn BACKGROUND and wait until the measure-
ment time is over.
Empty calibration
Source is mounted and beam path open (see chapter 7.2, page 3-
413). The tank is empty or the level below the limit value.
Select ReadIn Cal Point 0% and wait until the measurement
time is over.
Full Calibration
The beam path of the shielding is closed, or better, the tank is full.
Select ReadIn Cal Point 100% and wait until the measure-
ment time is over.
Calibration
Select Calibrate + Preset.
The message 0-OK must be displayed, otherwise correct the cali-
bration error as per the error message and reselect Calibrate +
Preset.
On the following pages you can find detailed calibration instructions.
Always carry out a test calculation after every calibration. This will
ensure that your calibration data are plausible and the detector is
set correctly (see chapter 2.39, page 3-366, Cps Average Mode
and Cps Average Test).
