5 Explosion Protection Volume 1
Plugs M20 x 1.5
Plugs 1/2" NPT
Material ID No. Ex labeling / Protection type AF Torque
Brass
nickel-plated
56093 PTB 09 ATEX 1002 X
IP66 / IP68 / IP69K
22 mm 10 Nm
Silicone
59031 LCIE08 ATEX 6085 X
IP66 / IP68 / IP69K
23 mm 6 Nm
Neoprene
Stainless steel
56094 PTB 09 ATEX 1002 X
IP66 / IP68 / IP69K
22 mm 10 Nm
Silicone
59032 LCIE08 ATEX 6085 X
IP66 / IP68 / IP69K
23 mm 6 Nm
Neoprene
Material ID No. Ex labeling AF Torque
Brass
nickel-plated
33910 File: 11716
Class: 4418-03
(USA + Kanada)
10 mm 30 Nm
Stainless steel
316L
66050 File: 215040
Class: 2258-02 (Kanada)
Class: 2258-82 (USA)
10 mm 30 Nm
