SENSseries LB 480
BERTHOLD TECHNOLOGIES GmbH & Co. KG
1 – 53
Volume 1 5 Explosion Protection
1
5.8.2 Plan for Inspection of the Terminal Compart-
ment
If you answer one of the following questions with "No", you have to
record the action you have taken to remedy this deficiency in the
last column. Make sure before you take the device into operation
again that the provisions you have taken are correct by consulting
with the person in charge of explosion protection.
Date: ...............................................
Name:.................................................
Yes No Measures
Test in the terminal compartment
Is the interior (terminal compartment) in
perfect order?
Is the interior dry, clean and free of foreign
material?
Are the cables connected firmly?
Are the terminals in perfect order?
Is the interior free of corrosion?
Is the insulation free of damages or trails?
Is the mechanical fastening of the fixtures
in good working order?
Is the detector installed according to the
local constructor regulations
(e.g. EN 60079-14)?
Does the cable insulation extend into the
terminal compartment?
Does the wire isolation reach into the sleeve
of the terminals, respectively the sleeve of
the ferrules?
When using ferrules: Does the sleeve of the
ferrule extend into the terminal sleeve?
Are all the wires of a fine-wire strand cov-
ered by the terminal and clamped?
Is the grounding conductor properly
installed?
Is the screened cable properly insulated
electrically up to the terminal (e.g. with
shrink tubing)?
