WHEELS-BRAKES-
SUSPENSIONS
6
Unscrew the four retaining bolts (9) securing the front calipers to the fork legs.
Recover the spacers (11).
Unscrew the special screws (1) from both calipers and recover sealing washers (2).
Detach the front brake calipers from the brake hose (3).
IMPORTANT
The brake caliper manufacturer advises against any servicing of the internal components of
calipers. Incorrect overhaul of this safety-critical component can endanger rider safety.
An overhaul not correctly done can seriously endanger the pilot safety.
Operations should be limited to renewal of the pads, fasteners and the bleed valve assembly.
For the substitution of the components mentioned above refer to exploded draw at the beginning of
chapter.
Sub 6-10
