FRAME
7
Footpegs support removal
In order to remove the L.H. footpeg assembly first remove the gearchange pedal unit (24) from the
left footpeg support (2).
Unscrew the two screws (11) which fix the support to the engine plate then remove the footpeg
assembly (12).
It is also possible to remove the L.H. footpeg assembly together with the gearchange pedal group
as showed by the picture below.
Remove the two screws (3) which fix the support to the engine plate then remove the footpeg
assembly (2).
Sub 7-11
