bimota DB7 - Page 170

FRAME
7
Foot pegs removal
In order to remove the footpeg and the footpeg fork from the support (2) (12), unscrew and remove
the screws (1) (13).
In order to remove the footpeg (8) from the footpeg fork (7), remove the seeger (10) then slip the
pin (6) off releasing the footpeg and the spring (9). Operate in the same way for the L.H. foot peg.
Sub 7-12
