bimota DB7 - Page 171

FRAME
7
7.5 – SIDESTAND
1) screw M10x25 TCEI CZ
2) sidestand plate
3) complete sidestand
4) spring fixing screw
5) screw M4x8 TSPEI
6) sidestand foot
7) sidestand leg
8) screw M5x8 TBEI
9) screw
10) sensor plate
11) sidestand stopping plate
12) screw M5x10 TBEI
13) sensor support plate
14) sidestand switch
15) inner spring
15) outer spring
Sub 7-13
