FRAME
7
7.1- FRAME AND CHASSIS PLATES
1) frame
2) L.H. frame plate
3) R.H. frame plate
4) screw TCEI M10x1,25
5) nut M12x1,25 Gally
6) screw M6x12 TBEI
7) velnut M6
8) L.H.fairing fixing plate
9) screw M8x20 TSPEI
10) spacer
11) engine pin
12) frame support
13) rubber pad
14) R.H. fairing fixing plate
15) spacer
16) screw M6x10 TBEI
Sub 7-16
