TECHNICAL
SPECIFICATIONS
2
Description Size (mm) Torque (Nm) Notes
SEAT
Rider's seat fixing screw M5x12/16 6
Rear small seat fixing screw M5x12 6
FRONT FENDER
Fixing screw of front fender to holder M5x10 5
Fixing screw of fender holder small plate M5x16 6
BODYWORK
Fixing screw of plexiglass to upper fairing M4x16 3/man
Fixing nut of upper fairing and rear view mirrors to holder M6 10
Fixing screw of upper fairing closing bulkhead M4x16 3/man
Fixing screw of upper side fairings to upper fairing M6x16 8/man
Fixing screw of side fairings to the frame M6x20/25 10
Fixing screw of lower fairing to small plate M6x25 10
Fixing screw of lower fairing plate to frame M6x35 12
Fixing screw of front lower fairing to lower fairing M6x16 8/man
Fixing screw of front lower fairing to side fairings M6x16 8/man
Fixing screw of tail to the frame M8x20/35 22
Fixing screw of under tail closure M4x20 3/man
NOTES
The tightening torque must be applied slowly and gradually using a calibrated torque wrench tool.
In case of screwing with automatic impact wrench, the reference torque must be reduced of 10%.
Sub 2-17
