TECHNICAL
SPECIFICATIONS
2
Description Size (mm) Torque (Nm) Notes
OIL RADIATOR
Oil radiator nipple on carter M14x1,5 25 Loctite 243
Oil radiator hose union on carter nipple M16x1,5 25 Lub with motor oil
Oil radiator hose union on radiator nipple M16x1,5 18 Lub with motor oil
Fixing screw of the radiator stirrup to head M6x12 10
Screw + fixing nut of the radiator to stirrup M6x25 10
FUEL TANK
Fixing screw of fuel cap to tank M5x12 5
Fixing screw of fuel pump to tank M5x16 5 Loctite 243
Fixing screw of tank rear support plate to tank M6x25 10 Loctite 243
Fixing screw of tank rear support plate to rear frame bar M6x12 12
Vent hoses union and tank drain M7 man
FEEDING - INTAKE - CANISTER
Fixing screw of intake cones to throttle body M5x16 5 Loctite 243
Fixing collar of throttle body to intake manifold -- 2,5
Fixing screw of intake cones to airbox bottom M6x12 10
Fixing screw of injection support to airbox M5x30 5
Fixing screw of intake air hoses manifold to airbox M5x12 5
Screw + fixing nut of canister support small plate to tail M6x14 10
Screw + fixing nut of canister small plate to support plate M6x20 10
EXHAUST
Fixing nut of exhaust manifold to head M6x1 10
CO cap M10x1,25 25
Fixing screw of silencer stirrup to tail M6x16 10 Loctite 243
Screw + fixing nut of silencer plate to stirrup M6x30 10
Fixing screw of plate to silencer M6x16 10 Loctite 510
Screw + fixing nut of mid-pipe to frame/mid-pipe fixing stirrup M6x30 10 Loctite 128455
Mid-pipe protection fixing screw M5x10/16 6 Loctite 128455
NOTES
The tightening torque must be applied slowly and gradually using a calibrated torque wrench tool.
In case of screwing with automatic impact wrench, the reference torque must be reduced of 10%.
Sub 2-16
