TECHNICAL
SPECIFICATIONS
2
Description Size (mm) Torque (Nm) Notes
Gear stop lever bolt M8x1,25 18 LOCK 2 or TB1324
Blow-by valve bolt M6x1 10
Chain side secondary bearing retaining bolt M6x1 10 LOCK 2
Clutch side primary bearing retaining bolt M6x1 10 LOCK 2 or TB1324
Crankcase screw – idler area M6x1 10
Outer crankcase screw M6x1 9
Oil pick-up gauze filter bolt M6x1 14
Left-hand side crankcase cover screw M6x1 10
Bosch sensor bolt M6x1 10
Right-hand side crankcase cover screw M6x1 9
Chain cover oil circuit blanking screw M6x1 5 LOCK 5
Right-hand side crankcase cover screw M6x1 9
Under-piston oil jet retaining screw M5x0,8 8 LOCK 2 or TB1324
Oil cooler nipple M14x1,5 27 LOCK 5 or TB 1375B
Vertical cylinder cover bolt:
Stage 1
Stage 2
M8x1,25
19
25
Crankcase hollow screw M8x1,25 20
Left-hand side crankcase cover screw M6x1 10
Drylock left-hand side crankcase cover screw M6x1 10 Pre-applied Loctite 516
Starter motor mounting bolt M6x1 10 LOCK 2 or TB1324
Starter motor rear bolt M6x1 10 LOCK 2 or TB1324
Idler gear shaft retaining bolt M6x1 10 LOCK 2 or TB1324
Front sprocket retaining nut M24x1 190 GREASE B
Flywheel retaining nut M24x1 330 LOCK 5
Connecting rod cap bolts:
Stage 1
Pause for 2 sec., then back off through 360°
Stage 1
Stage 2
Tighten down to 65°±1°
Torque check
M10x1
35
20
35
70±103
Apply
GREASE B
to thread
Crankshaft grub screw M8x1,25 13 TB1375B
Drilled crankshaft grub screw M8x1,25 13 TB1375B
Selector drum locating screw M16x1,5 30
Gear stop lever screw M8x1,25 18 LOCK 2 or TB1324
Selector claw bolt M8x1,25 25
Selector claw locator nut M6x1 10
Sub 2-19
