TECHNICAL
SPECIFICATIONS
2
Description Size (mm) Torque (Nm) Notes
Selector claw bolt M6x1 9 LOCK 2 or TB1324
Idler and tensioner pulley bolts M20x1 50 LOCK 2 or TB1324
Camshaft pulley retaining nut M15x1 71 GREASE A
Timing belt driveshaft gear nut M14x1 55 GREASE A
Idler and tensioner pulley nut M8x1,25 25 GREASE A
Timing belt cover screw M6x1 10 LOCK 2 or TB1324
Self-tapping screw for timing belt cover filter M3,5
Dry clutch centre nut M25x1 250 LOCK 5
Oil filler plug M22x1,5 5
Wet clutch centre nut M20x1 120 GREASE B
Oil temperature sensor M12x1,5 18 LOCK 4
Oilway blanking plug M10x1 20 LOCK 5
Dry clutch drum bolts M8x1,25 35 LOCK 4
Right-hand side crankcase cover screw M6x1 9
Clutch spring bolt M5x0,8 5
Coolant inlet union M30x1,5 25 LOCK 5
Coolant outlet union M22x1,5 25 LOCK 5
Pick-up sensor inspection screw M12x1 15 LOCK 2 or TB1324
Water pump cover plug M10x1 20
Spark plug M10x1 12
Coolant pump bearing stop screw M6x1 10 LOCK 2 or TB1324
Stator wiring clamp bracket bolt M6x1 10 LOCK 2 or TB1324
Water pump cover plug M6x1 10
Left-hand crankcase cover screw M6x1 10
Inspection cover screw M6x1 4,5
Alternator rotor/flywheel bolt M6x1 13 LOCK 2 or TB1324
By-pass pump cap M15x1 25 LOCK 2 or TB1324
Oil pump retaining bolt M6x1 10
Oil pump retaining bolt M8x1,25 26
Oil pump retaining bolt M6x1 10
Coolant outlet union M22x1,5 25 LOCK 5
Coolant circuit hose clamps 2,5
Sub 2-20
