BONFIGLIOLI active cube 201 User Manual

12/16
Operating Instructions ACU
275
Pulse width modulation
No.
Description
Unit
Setting range
Chapter
580
Reduction limit Ti/Tk
deg.C
-25 ... 0
19.1
V-belt monitoring
581
Operation mode
-
Selection
19.6
582
Trigger limit Iactive
%
0.1 ... 100.0
19.6
583
Delay time
s
0.1 ... 600.0
19.6
V/f characteristic
600
Starting voltage
V
0.0 ... 100.0
17
601
Voltage rise
%
-100 ... 200
17
602
Rise frequency
%
0 ... 100
17
603
Cut-off voltage
V
60.0 ... 560.0
17
604
Cut-off frequency
Hz
0.00 ... 599.00
17
605
Dyn. Voltage Pre-Control
%
0 ... 200
17.1
Current limit value controller
610
Operation mode
-
Selection
18.4.2
611
Amplification
-
0.01 ... 30.00
18.4.2
612
Integral Time
ms
1 … 10000
18.4.2
613
Current Limit
A
0.0 ... oI
FIN
18.4.2
614
Frequency Limit
Hz
0.00 ... 599.00
18.4.2
Error/warning behavior
617
max.Temp. Windings
°C
0 … 200
14.6
Technology controller
618
Derivative time
ms
0 … 1000
18.3
Starting behavior
620
Operation mode
-
Selection
13.1.1
621
Amplification
-
0.01 ... 10.00
13.1.1
622
Integral Time
ms
1 ... 30000
13.1.1
623
Starting current
A
0.0 ... oI
FIN
13.1.1.1
624
Frequency Limit
Hz
0.00 ... 100.00
13.1.1.2
625
Brake Release Time
ms
-5000 … 5000
13.1.1.3
Application Warnings
626
Create warning mask application
-
Selection
16.3.9
Stopping behavior
630
Operation mode
-
Selection
13.2
Direct current brake
631
Braking current
A
0.00 ... 2I
FIN
13.3
632
Braking time
s
0.0 ... 200.0
13.3
633
Demagnetizing time
s
0.1 ... 30.0
13.3
634
Amplification
-
0.00 ... 10.00
13.3
635
Integral Time
ms
0 ... 1000
13.3
Stopping behavior
637
Switch-Off Threshold
%
0.0 ... 100.0
13.2.1
638
Holding time
s
0.0 ... 200.0
13.2.2
Search run
645
Operation mode
-
Selection
13.5
646
Brak. time after search run
s
0.0 ... 200.0
13.5
647
Current / Rated Motor Current
%
1.00 ... 100.00
13.5
648
Amplification
-
0.00 ... 10.00
13.5
649
Integral Time
ms
0 ... 1000
13.5
