BONFIGLIOLI active cube 201 User Manual

274
Operating Instructions ACU
12/16
Speed controller
No.
Description
Unit
Setting range
Chapter
515
Integral Time Speedtracking
ms
1 … 60 000
18.5.4.3
Digital Outputs
517
Setting Frequency Off Delta
Hz
0.00 … 599.00
16.3.2
Percentage Value Limits
518
Minimum Reference Percentage
%
0.00 ... 300.00
15.3
519
Maximum Reference Percentage
%
0.00 ... 300.00
15.3
Fixed percentages
520
Fixed Percentage 1
%
-300.00 ... 300.00
15.6.3
521
Fixed Percentage 2
%
-300.00 ... 300.00
15.6.3
522
Fixed Percentage 3
%
-300.00 ... 300.00
15.6.3
523
Fixed Percentage 4
%
-300.00 ... 300.00
15.6.3
Digital Outputs
530
Op. Mode Digital Output 1
-
Selection
16.3
532
Op. Mode Digital Output 3
-
Selection
16.3
535
Op. Mode ext. Error
-
Selection
16.4.12
536
Create warning mask
-
Selection
16.3.8
540
Op. Mode Comparator 1
-
Selection
16.5.2
541
Comparator On above
%
-300.00 ... 300.00
16.5.2
Digital Outputs
542
Comparator Off below
%
-300.00 ... 300.00
16.5.2
543
Op. Mode Comparator 2
-
Selection
16.5.2
544
Comparator On above
%
-300.00 ... 300.00
16.5.2
545
Comparator Off below
%
-300.00 ... 300.00
16.5.2
549
Max. Control Deviation
%
0.01 ... 20.00
16.3.3
Multifunction output 1
550
Operation mode
-
Selection
16.2.2
551
Voltage 100%
V
0.0 ... 22.0
16.2.1.1
552
Voltage 0%
V
0.0 ... 24.0
16.2.1.1
553
Analog Operation
-
Selection
16.2.1
554
Digital Operation
-
Selection
16.3
Multifunction output 1
555
Repetition frequency operation
-
Selection
16.2.2
556
Division Marks
-
30 ... 8192
16.2.2.1
Error/warning behavior
570
Motor Temp. Operation Mode
-
Selection
14.6
Motor circuit breaker
571
Operation mode
-
Selection
19.5
572
Frequency Limit
%
0 ... 300
19.5
Intelligent current limits
573
Operation mode
-
Selection
18.1
574
Power Limit
%
40.00 ... 95.00
18.1
575
Limitation Time
min
5 ... 300
18.1
Error/warning behavior
576
Phase supervision
-
Selection
14.7
578
Allowed no. of AutoAck.
-
0 ... 20
14.8
579
Restart delay
ms
0 ... 1000
14.8
