Operating Instructions ACU
273
Temperature Adjustment
No.
Description
Unit
Setting range
Chapter
465
Operation mode
-
Selection
19.7.2
466
Temperature coefficient
%/100
0.00 ... 300.00
19.7.2
467
Adjusting temperature
deg.C
-50.0 ... 300.0
19.7.2
Positioning
469
Reference orientation
°
0.0 ... 359.9
13.6.2
471
Positioning Frequency
Hz
1.00 ... 50.00
13.6.2
472
Max positional error
°
0.1 ... 90.0
13.6.2
Motor potentiometer
473
Ramp Keypad Motorpoti
Hz/s
0.01 ... 999.99
15.10.3
474
Operation mode
-
Selection
15.10
Reference Frequency Channel
475
Reference frequency source
-
Selection
15.4
Reference percentage channel
476
Reference Percentage Source
-
Selection
15.5
Percentage ramp
477
Gradient Percentage Ramp
%/s
0 ... 60000
15.8
Technology controller
478
Actual percentage source
-
Selection
18.3
Positioning
479
time constant positioning contr.
ms
1.00 ... 9999.99
13.6.2
Fixed frequencies
480
Fixed Frequency 1
Hz
-599.00 ... 599.00
15.6.1
481
Fixed Frequency 2
Hz
-599.00 ... 599.00
15.6.1
482
Fixed Frequency 3
Hz
-599.00 ... 599.00
15.6.1
483
Fixed Frequency 4
Hz
-599.00 ... 599.00
15.6.1
489
JOG frequency
Hz
-599.00 ... 599.00
15.6.2
Speed Sensor 1
490
Operation mode
-
Selection
11.4.1
491
Division Marks
-
1 ... 8192
11.4.2
PWM-/repetition frequency input
496
Operation mode
-
Selection
15.11
497
Divider
-
1 ... 8192
15.11
Brake Chopper
506
Trigger Threshold
V
225 ... 1000 (201)
425 ... 1000 (401)
925 … 1050 (501)
1225 … 1400 (601)
19.4
Motor chopper
507
Trigger Threshold
V
225 ... 1000 (201)
425 ... 1000 (401)
925 … 1050 (501)
1225 … 1400 (601)
19.7.1
Digital Outputs
510
Setting Frequency
Hz
0.00 ... 599.00
16.3.2
Speed Sensor 1
511
EC1 Gear Factor Numerator
-
-300.00 … 300.00
11.4.3
512
EC1 Gear Factor Denominator
-
0.01 … 300.00
11.4.3
