Page #276 background image
276
Operating Instructions ACU
12/16
Auto start
No.
Description
Unit
Setting range
Chapter
651
Operation mode
-
Selection
13.4
PWM-/repetition frequency input
652
Offset
%
-100.00 … 100.00
15.11
653
Amplification
%
5.0 … 1000.0
15.11
Slip compensation
660
Operation mode
-
Selection
18.4.1
661
Amplification
%
0.0 ... 300.0
18.4.1
662
Max. slip ramp
Hz/s
0.01 ... 650.00
18.4.1
663
Minimum frequency
Hz
0.01 ... 599.00
18.4.1
Voltage controller
670
Operation mode
-
Selection
18.2
671
Mains failure threshold
V
-200.0 ... -50.0
18.2
672
Reference mains support value
V
-200.0 ... -10.0
18.2
673
Mains support deceleration
Hz/s
0.01 ... 9999.99
18.2
674
Acceleration on mains resumption
Hz/s
0.00 ... 9999.99
18.2
675
Shutdown threshold
Hz
0.00 ... 599.00
18.2
676
Reference shutdown value
V
225.0 … 387.5 (201)
425.0 … 770.0 (401)
550.0 … 875.0 (501)
725.0 … 1175.0 (601)
18.2
677
Amplification
-
0.00 ... 30.00
18.2
678
Integral Time
ms
0 ... 10000
18.2
680
Reference DC link limitation
V
225.0 … 387.5 (201)
425.0 … 770.0 (401)
550.0 … 875.0 (501)
725.0 … 1175.0 (601)
18.2
681
max. frequency rise
Hz
0.00 ... 599.00
18.2
683
Gen. Ref. Current Limit
A
0.0 ... oI
FIN
18.2
Current controller
700
Amplification
-
0.00 ... 8.00
18.5.1
701
Integral Time
ms
0.00 ... 10.00
18.5.1
Further motor parameters
713
Magnetizing current 50% flux
%
1 ... 50
11.2.3
714
Magnetizing current 80% flux
%
1 ... 80
11.2.3
715
Magnetizing current 110% flux
%
110 ... 197
11.2.3
716
Rated magnetizing current
A
0.01I
FIN
... oI
FIN
11.2.3
Field controller
717
Reference Flux
%
0.01 ... 300.00
18.5.6
Further motor parameters
718
Rated slip correction factor
%
0.01 ... 300.00
11.2.4
Frequency Limits
719
Slip Frequency
%
0 ... 10000
15.2
Speed controller
720
Operation mode
-
Selection
18.5.4
721
Amplification 1
-
0.00 ... 200.00
18.5.4
722
Integral Time 1
ms
0 ... 60000
18.5.4
723
Amplification 2
-
0.00 ... 200.00
18.5.4
724
Integral Time 2
ms
0 ... 60000
18.5.4
