BONFIGLIOLI active cube 201 User Manual

278
Operating Instructions ACU
12/16
Torque controller
No.
Description
Unit
Setting range
Chapter
767
Frequency upper limit
Hz
-599.00 ... 599.00
18.5.2
768
Frequency lower limit
Hz
-599.00 ... 599.00
18.5.2
769
Frequency upper limit source
-
Selection
18.5.3.3
770
Frequency lower limit source
-
Selection
18.5.3.3
Current controller
775
Current above P. 700 is in effect
A
0.00 ... oI
FIN
18.5.2
776
Current below P. 777 is in effect
A
0.00 ... oI
FIN
18.5.2
777
Amplification low Current
-
0.00 ... 8.00
18.5.2
Field controller
778
Reduction Factor Flux
%
20 … 100
18.5.6
Starting behavior
779
Minimum flux formation time
ms
1 ... 10000
13.1.2
780
Max. Flux-Formation Time
ms
1 ... 10000
13.1.2
781
Current during flux formation
A
0.1I
FIN
... oI
FIN
13.1.2
Timer
790
Operation Mode Timer 1
-
Selection
16.5.1
791
Time 1 Timer 1
s/m/h
0 ... 650.00
16.5.1.1
792
Time 2 Timer 1
s/m/h
0 ... 650.00
16.5.1.1
793
Operation Mode Timer 2
-
Selection
16.5.1
794
Time 1 Timer 2
s/m/h
0 ... 650.00
16.5.1
795
Time 2 Timer 2
s/m/h
0 ... 650.00
16.5.1
Auto set-up
796
SET-UP Select
-
Selection
9.5
Further motor parameters
1190
Stator resistance
Ohm
0.001 … 100.000
11.2.1
1192
Peak current
A
0.01% I
FIN
…
100 000% o I
FIN
11.2.7
Encoder 1 Filter time constant
1193
EC1: Filter time constant
us
0...32000
11.4.4
Further motor parameters
1199
Reverse sense of rotation
-
Selection
11.2.8
Mux/DeMux
1250
Mux input index (write)
-
EEPROM:
0 … 16
16.5.4
RAM:
17 … 33
1251
Mux input index (read)
-
EEPROM:
0 … 16
16.5.4
RAM:
17 … 33
1252
Mux inputs
-
Selection
16.5.4
1253
DeMux Input
-
Selection
16.5.4
User Warning
1363
User Warnig 1
-
Selection
16.4.11
1364
User Warnig 2
-
Selection
16.4.11
Profibus/Internal Notation converter
1370
In-F-PDP-word 1
Selection
19.9
1371
In-F-PDP-word 2
Selection
19.9
1372
In-F-intern long 1
Selection
19.9
1373
In-F-intern long 2
Selection
19.9
1374
In-F-Convert Reference
Hz
0.01...599.00
19.9
