16
Panel Descriptions
15 REC (Recording) button
This is the Record button. In addition to the Recording
operation, it is also used for manual punch-in/out. While in
recording standby, the indicator on this button flashes in red,
and during recording, it lights in red.
16 AUDIO TRACK MIXER fader 1–4
For controlling the volumes of each track during playback.
* Hereafter, the AUDIO TRACK MIXER faders shall be
referred to as the “TRACK faders.”
17 MASTER fader
Controls the overall volume of the BR-532.
18 REC TRACK (Recording Track)
button 1–4
Use these buttons to select to which track you will record.
The button of the track selected will flash in red and then
light in red when recording begins. When recording is
finished, the button of the selected track will light alternately
in orange and green.
The relationship between the indicator and the track
conditions is given below.
Off:
This track contains no recorded data.
Green:
An audio track that contains recorded data.
Flashing in red:
The track is selected as the recording destination, and is
in recording standby.
Red:
This track currently being recorded.
Lighting alternately in orange and green:
This track contains recorded data and is selected for
recording.
19 V-TRACK button
Use this button to call up the screen for selecting a V-Track.
What are V-Tracks? (p. 11)
Utilizing the V-Tracks (p. 99)
20 LOOP EFFECTS button
Use this button to call up the screen for setting the send level
of each track respective to the loop effects (p. 42), switching
between reverb and chorus, setting the various parameters,
and more (p. 82).
Loop Effect Parameter Functions (p. 85)
21 PAN button
Pressed to access a screen where you can set the pan (left/
right location of the sound) for the playback of each track or
for the input sound (p. 42).
22 PHRASE TRAINER button
Use this button to perform the settings for the phrase trainer
function.
When using the phrase trainer, you can turn on or off the
center cancel function (for removing vocals at the center), or
the time stretch function (for slowing down playback).
Canceling the center sound (p. 78)
Slowing down the speed (p. 78)
23 BOUNCE ON/OFF button
Use this button to mix the recordings on several tracks
together onto one or two other tracks.
24 BOUNCE MODE Indicator
Indicates the recording track at the bounce destination. The
relevant indicator lights depending on whether the track
being recorded is stereo or monaural.
