5.1.69 Discharging Brush PU
(1) Remove the hinge cover.
(2) Remove the setscrew (BT3x8, 2 pieces) of the shaft holder.
(3) Remove the shaft holder from the exit guide ASSY PU.
(4) Remove the discharging brush PU from the exit guide ASSY PU.
Fig. 5-117
Hinge cove
r
BT3X8
BT3
x
8
Discharging brush PU
Shaft holde
r
Exit guide
A
SS
Y
PU
Hooks
