Confidential
5-82
5.3 HARNESS ROUTING
ADF unit
1
Side cover L
Hole
Hole
Main PCB
ADF motor
ADF sensor PCB
Hooks
Hole
ADF unit
Document scanner
Insert
Ground wire
