Brother MFC-9420CN Service Manual

8-32 Confidential
8.2.3.2 Next Care Information (Code 32)


 Function
This function is to get the information on the replacement timing of the periodical
replacement parts.
The information includes the number of images and print pages.


 Operating Procedure
(1) Select Next Care with using the 4 or 5 key in the initial stage of the engine service mode.
After selecting, press the 6 key.
The “32 NEXT CARE / ▲ 2 3 4 5 6 7 8 9 A B C D E F G” appears on the LCD.
(2) Select the periodical replacement part whose information you want to get with using the
4 or 5 key.
7: Belt cartridge (BC)
8: Fusing unit (FU)
9: Transfer belt (TB)
A: 120K KIT (OW)
D: Pick-up roller (machine) (PK)
E: Pick-up roller (LFU) (Option tray) (PL)
(3) After selecting, press the 6 key.
The machine displays the replacement timing of the selected periodical replacement
parts.
(4) Press the 3 key so that the “32 NEXT CARE / ▲ 2 3 4 5 6 7 8 9 A B C D E F G”
appears on the LCD. When you want to get the information on other periodical
replacement parts, repeat Step (2) to (4).
(5) Press the 3 key again, and the machine returns to the initial stage of the engine service
mode.
NOTE: The replacement timing indication of the periodical replacement parts can be
changed in the Next Life Set mode (Code 49). It is also changed as follows
whenever the total number of print pages is increased during normal usage.
• OPC belt cartridge: Life 60,000 images
If the coverage on a page is large, the load for the OPC belt cartridge gets high,
and its life is shorter than the actual number of images. Therefore, the
indication may be decreased depending on the coverage of each print page.
(For details, refer to the following page.)
• Fusing unit: Life 60,000 pages
For example, the lamp of the fusing unit is turned ON and OFF 10 times if one
page is printed per print job, and 10 pages are printed totally. On the other hand,
the lamp is turned ON and OFF once if 10 pages are printed per print job. The
load for the fusing unit is widely different even though the same number of
pages is printed, and the life of the fusing unit is also different. Therefore, the
indication may be decreased more than the number of print pages when few
pages are printed per print job. (For details, refer to the following page.)
• Transfer belt: Life 120,000 pages
It is not changed.

Brother MFC-9420CN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	31 ppm
Print speed (color, normal quality, A4/US Letter)	8 ppm
Digital sender	No
Number of print cartridges	4
Scanner type	Flatbed scanner
Scanner features	Scan to: e-mail, image, OCR, file
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	31 cpm
Copy speed (color, normal quality, A4)	8 cpm
Faxing	Color faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	200
Total input capacity	750 sheets
Maximum input capacity	250 sheets
Auto document feeder (ADF) input capacity	35 sheets
Maximum internal memory	576 MB
Bundled software	ScanSoft PaperPort Presto! PageManager
I/O ports	IEEE-1284 USB 2.0
Dimensions (WxDxH)	483.5 x 514 x 530 mm
Printer management	BRAdmin Professional, MIB-II
Networking features	10Base-T/100Base-TX
All-in-one functions	Fax, Scan
Color all-in-one functions	copy, fax, print, scan
Compatible operating systems	Windows 98(SE)/ Me/ NT WorkStation 4.0/ 2000 Professional/ XP Mac OS 9.1 - 9.2, Mac OS X 10.2.4+
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	1090 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Market positioning	Business
