Brother MFC-9420CN - Equipment Outline; Control Panel

1-1 Confidential
1.1 EQUIPMENT OUTLINE
Front view
Fig. 1-1
Back view
Fig. 1-2
ADF Document Output Support Flap
Document Cover
Front Cover
Paper Tray
Control Panel
USB Interface Connector
Parallel Interface Connector
AC Power Connector
Back Cover
Automatic Document Feeder (ADF)
Back Cover
Face-down Output Tray
Support Flap with Extension
(Support Flap)
Power Switch
