Brother MFC-9420CN Service Manual

8-36 Confidential
8.2.3.5 Each Image (Code 35)


 Function
This function is to check the image counter of each color to be used in printing.


 Operating Procedure
(1) Select the Each Image mode with using the 4 or 5 key in the initial stage of the engine
service mode.
After selecting, press the 6 key.
The “35 IMAGE OF / ► Y / M / C / K” appears on the LCD.
(2) Select the color you want to check with using the 4 or 5 key and press the 6 key.
The image counter such as “35 IMAGE OF Y / 0 0 0 0 9 8 P” appears on the LCD.
(3) Press the 3 key so that the display is returned to the message described in Step (1).
(4) When checking the image counter of other colors, repeat Step (2) and (3).
(5) Press the 3 key, and the machine returns to the initial stage of the engine service mode.

Brother MFC-9420CN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	31 ppm
Print speed (color, normal quality, A4/US Letter)	8 ppm
Digital sender	No
Number of print cartridges	4
Scanner type	Flatbed scanner
Scanner features	Scan to: e-mail, image, OCR, file
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	31 cpm
Copy speed (color, normal quality, A4)	8 cpm
Faxing	Color faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	200
Total input capacity	750 sheets
Maximum input capacity	250 sheets
Auto document feeder (ADF) input capacity	35 sheets
Maximum internal memory	576 MB
Bundled software	ScanSoft PaperPort Presto! PageManager
I/O ports	IEEE-1284 USB 2.0
Dimensions (WxDxH)	483.5 x 514 x 530 mm
Printer management	BRAdmin Professional, MIB-II
Networking features	10Base-T/100Base-TX
All-in-one functions	Fax, Scan
Color all-in-one functions	copy, fax, print, scan
Compatible operating systems	Windows 98(SE)/ Me/ NT WorkStation 4.0/ 2000 Professional/ XP Mac OS 9.1 - 9.2, Mac OS X 10.2.4+
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	1090 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Market positioning	Business
