Brother MFC-9420CN - Tightening Torque

Confidential
5-2


 Tightening Torque
Location of screw Screw type Q'ty Tightening torque
N•m (kgf•cm)
FB motor Screw, pan (s/p washer) M3x6 2 0.59 ±0.1 (6 ±1)
Gear holder ASSY Taptite, cup B M3x10 2 0.49 ±0.1 (5 ±1)
Scanner top cover ASSY Taptite, bind B M4x12 6 0.78 ±0.1 (8 ±1)
2
2
4
Drive frame ASSY
Upper document chute
Lower document chute
Hinge ASSY L
Taptite, cup B M3x10
3
0.49 ±0.1 (5 ±1)
Hinge arm 1
For preventing the hinge ASSY L
from coming out
Taptite, bind B M4x12
1
0.78 ±0.1 (8 ±1)
ADF motor Taptite, bind S M3x6 1 0.69 ±0.1 (8 ±1)
FG connection Taptite, cup S M3x6 1 0.78 ±0.1 (8 ±1)
Guide gear Taptite, B M3x6 1 0.29 ±0.5 (3 ±0.5)
