Brother MFC-9420CN Service Manual

8-38 Confidential
8.2.3.8 Extend Media (Code 38)


 Function
This function is to set the details on the recording paper type.
・Two types of normal and thin paper are provided for the plain paper.
・Two types of normal and extreme thick paper are provided for the label.


 Operating Procedure
(1) Select the Extend Media mode with using the 4 or 5 key in the initial stage of the engine
service mode.
After selecting, press the 6 key.
The “38 EXTEND MEDIA / ► PPC / MTS / TS” appears on the LCD.
(2) Select the recording paper you want to set with using the 4 or 5 key and press the 6 key.
PPC: Plain paper
MTS: Label
TS: Thick paper
(3) Select the detailed type of the selected recording paper with using the 4 or 5 key and
press the 6 key.
Setting type
PPC: Normal / Thin
MTS: Normal / Glossy
TS: TS1 (Thick paper) / TS2 (extreme thick paper)
(4) Press the 3 key, and the machine returns to the initial stage of the engine service mode.
8.2.3.9 Factory Mode (Code 39)


 Function
It is composed of the nine modes including the functions to check the performance and to set
the required items in maintenance work.
[ 1 ] Margin Adjust
[ 2 ] Life Period Set
[ 3 ] NVRAM Tune Up
[ 4 ] NVRAM Initial
[ 5 ] Total Page Set
[ 6 ] Each Image Set
[ 7 ] Next Life Set

Brother MFC-9420CN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	31 ppm
Print speed (color, normal quality, A4/US Letter)	8 ppm
Digital sender	No
Number of print cartridges	4
Scanner type	Flatbed scanner
Scanner features	Scan to: e-mail, image, OCR, file
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	31 cpm
Copy speed (color, normal quality, A4)	8 cpm
Faxing	Color faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	200
Total input capacity	750 sheets
Maximum input capacity	250 sheets
Auto document feeder (ADF) input capacity	35 sheets
Maximum internal memory	576 MB
Bundled software	ScanSoft PaperPort Presto! PageManager
I/O ports	IEEE-1284 USB 2.0
Dimensions (WxDxH)	483.5 x 514 x 530 mm
Printer management	BRAdmin Professional, MIB-II
Networking features	10Base-T/100Base-TX
All-in-one functions	Fax, Scan
Color all-in-one functions	copy, fax, print, scan
Compatible operating systems	Windows 98(SE)/ Me/ NT WorkStation 4.0/ 2000 Professional/ XP Mac OS 9.1 - 9.2, Mac OS X 10.2.4+
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	1090 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Market positioning	Business
