Brother MFC-9420CN Service Manual

Confidential
CHAPTER 9 ERROR INDICATION AND TROUBLESHOOTING
This chapter details error messages and codes that the incorporated self-diagnostic
functions display if any error or malfunction occurs. If any error message appears, refer
to this chapter to find which components should be checked or replaced.
The latter half of this chapter provides sample problems that could occur in the main
sections of the machine and related troubleshooting procedures. This will help service
personnel pinpoint and repair defective components.
CONTENTS
9.1 ERROR INDICATION ...................................................................................................... 9-1
9.1.1 Equipment Errors................................................................................................. 9-1
[ 1 ] Error messages appearing on the LCD....................................................... 9-1
[ 2 ] Error codes shown in "MACHINE ERROR X
X" messages........................ 9-5
9.1.2 Communications Errors ..................................................................................... 9-15
9.2 TROUBLESHOOTING .................................................................................................. 9-19
9.2.1 Introduction ........................................................................................................ 9-19
9.2.2 Precautions........................................................................................................ 9-19
9.2.3 Checking Prior to Troubleshooting .................................................................... 9-19
9.2.4 Troubleshooting Based on Problem Type ......................................................... 9-20
[ 1 ] Software setting problems ......................................................................... 9-20
[ 2 ] Image failure .............................................................................................. 9-23
[ 3 ] Paper transport error ................................................................................. 9-50
[ 4 ] Incorrect printout........................................................................................ 9-52
[ 5 ] Network problem ....................................................................................... 9-54
[ 6 ] Troubleshooting of the control panel ......................................................... 9-58
[ 7 ] Troubleshooting of fax functions ............................................................... 9-60

Brother MFC-9420CN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	31 ppm
Print speed (color, normal quality, A4/US Letter)	8 ppm
Digital sender	No
Number of print cartridges	4
Scanner type	Flatbed scanner
Scanner features	Scan to: e-mail, image, OCR, file
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	31 cpm
Copy speed (color, normal quality, A4)	8 cpm
Faxing	Color faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	200
Total input capacity	750 sheets
Maximum input capacity	250 sheets
Auto document feeder (ADF) input capacity	35 sheets
Maximum internal memory	576 MB
Bundled software	ScanSoft PaperPort Presto! PageManager
I/O ports	IEEE-1284 USB 2.0
Dimensions (WxDxH)	483.5 x 514 x 530 mm
Printer management	BRAdmin Professional, MIB-II
Networking features	10Base-T/100Base-TX
All-in-one functions	Fax, Scan
Color all-in-one functions	copy, fax, print, scan
Compatible operating systems	Windows 98(SE)/ Me/ NT WorkStation 4.0/ 2000 Professional/ XP Mac OS 9.1 - 9.2, Mac OS X 10.2.4+
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	1090 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Market positioning	Business
