6-9 Confidential
(4) To lock the cartridge into the machine, push the belt cartridge lock levers that are on both
sides of the OPC belt cartridge outwards.
Fig. 6-8
(5) Close the center cover, and then close the scanner unit.
(6) Turn the machine’s power switch back on.
< How to reset the OPC Belt life counter >
Resetting the OPC belt cartridge life counter from the normal standby status (supporting
ver.0.35 or later of the firmware)
(1) Press the 1 and 7 keys at the same time.
The “OPC Belt/1. Reset 2 Exit” message appears on the LCD.
(2) Press the 1 key.
The OPC belt cartridge life counter is reset, and the machine returns to the normal
standby status.
Resetting the OPC belt cartridge life counter from the maintenance mode (supporting all
versions of the firmware)
(1) Press the Menu/Set and Black Start keys. Next press the
key four times to make the
machine enter the maintenance mode.
(2) Press the 8 and 0 keys in this order.
(3) Press the Black Start key a few times so that “OPC belt cartridge” appears on the LCD.
(4) Press the 2, 7, 8, 3 keys in this order. Then, the OPC belt cartridge life counter is reset.
(5) Press the Stop/Exit key so that the machine returns to the initial status of the
maintenance mode.
(6) Press the 9 key twice to exit from the maintenance mode.
Belt cartridge lock levers
Belt cartridge lock levers
