(2) Inner Jam
Problem item P# Check item Result Corrective action
Open the back cover assy PU
for check.
1
Is there any paper inside the
unit?
YES
Remove the paper inside.
Transportation Part
2
Is the transfer roller firmly
locked by the lock lever?
NO
Fix the transfer roller with
the lock lever.
3
Is the fusing unit properly
locked?
NO
Fix the fusing unit with
the FU lock lever.
Fusing unit
4
Is there any paper caught
between the rollers?
YES
Remove the caught paper.
To Next Page
