Brother MFC-9420CN Service Manual

2-9 Confidential
(6/6)
US/Canada Euro
p
e
A
sia/Pacific
Model Nam
e
NETWORK
Standard/Option
Model Name
Share Printer
Share Scanner
Share PC FAX
Internet FAX (ITU T.37 simple mode)
Scan to E-mail Server
ITU SUB Addressing
Support OS version
Network connection
Support Protocols
Network Management
Option
CONSUMABLE
Toner Cartridge Black
Toner Cartridge Cyan, Magenta, Yellow
Waste Toner Pack
OPC Belt
Fuser Unit
SERVICE (Not to be used in sales leaflet)
Machine Life
Monthly Volume
Periodical Replacement Parts
MTBF
MTTR
240,000-page or 5 years
30,000-page
NC-2200W, NC-2100p
0.5 hours or less
Transfer Roller 120,000-page
Transfer Belt Cleaner 120,000-images
Paper Pick-up Roller/ Separator Pad 120,000-page
Transfer Belt 300,000-images
5,000 hours
Standard
Embedded : NC-6300h
Yes
SL4C-FB
MFC-9420CN
Yes
Yes
Yes
N/A
FP-4CL : 60,000-page
WT-4CL : 12,000-image
OP-4CL : 60,000-image by coninuous printing
TN-04C,M,Y : up to 6,600 pages w/ 5% coverage
Win98(SE)/Me and NT4.0WS/2000/XP
Mac OS 9.1 - 9.2, Mac OS X 10.2.4 or greater
(Simple Network Configuration is supported with OS 10.2.4 or greater)
Ethernet 10/100Base-TX Auto Negotiation
Yes
TCP/IP
(TELNET, SNMP, HTTP, TFTP, ARP,RARP, BOOTP, DHCP, APIPA(Auto IP),
WINS/NetBIOS, DNS, LPR/LPD, Custom Raw Port/Port9100, POP3/SMTP, IPP,
FTP, mDNS)
BRAdmin Professional
Web Based Management
MIB-II as well as Brother private MIB
TN-04BK : up to 10,000 pages w/ 5% coverage

Brother MFC-9420CN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	31 ppm
Print speed (color, normal quality, A4/US Letter)	8 ppm
Digital sender	No
Number of print cartridges	4
Scanner type	Flatbed scanner
Scanner features	Scan to: e-mail, image, OCR, file
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	31 cpm
Copy speed (color, normal quality, A4)	8 cpm
Faxing	Color faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax speed dialing (max numbers)	200
Total input capacity	750 sheets
Maximum input capacity	250 sheets
Auto document feeder (ADF) input capacity	35 sheets
Maximum internal memory	576 MB
Bundled software	ScanSoft PaperPort Presto! PageManager
I/O ports	IEEE-1284 USB 2.0
Dimensions (WxDxH)	483.5 x 514 x 530 mm
Printer management	BRAdmin Professional, MIB-II
Networking features	10Base-T/100Base-TX
All-in-one functions	Fax, Scan
Color all-in-one functions	copy, fax, print, scan
Compatible operating systems	Windows 98(SE)/ Me/ NT WorkStation 4.0/ 2000 Professional/ XP Mac OS 9.1 - 9.2, Mac OS X 10.2.4+
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	16 W
Power consumption (average operating)	1090 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Market positioning	Business
