Confidential
3-31
Fig. 3-32
1. Paper Size Sensor PU
2. Registration Sensor PU
3. Fuser Exit Sensor PU
4. Tray Empty Sensor PU
5. OHP Sensor PU
7. Transfer Unit Sensor PU
8. OPC Marker Sensor PU
9. Toner Sensor PU
10. Waste Toner Sensor PU
11. Temperature Sensor for Fusing Unit
12. Output Tray Full Sensor PU
13. Toner Key Sensor PU
14. Room Temp. Thermistor Sensor PU
6. Toner Density Sensor PU
16. ADF Front Sensor
15. ADF Rear Sensor
ADF Sensor
To Next Page
