Confidential
3-42
(4) SO-DIMM
SO-DIMM allows memory extension by up to 576MB.
1 SO-DIMM socket is available.
The following type of DIMM can be installed into each slot.
• Type: 144 pin and 64 bit output
• Memory type: SDRAM
• Clock frequency: PC100 or PC133
• Parity: Non-parity can be used
• Memory capacity: 64MB, 128MB, 256MB, 512MB
• CAS latency: 2 or 3
<Recommended DIMM type>
<US>
* 64MB: Techworks 12345-0001
* 128MB: Techworks 12462-0002
* 256MB: Techworks 12469-0001
<Europe>
* 64MB: Buffalo Technology VN133-64M
* 128MB: Buffalo Technology VN133-128M
* 256MB: Buffalo Technology VN133-256M
* 512MB: Buffalo Technology VN133-512M
Any combination of DIMM size can be installed into any slot in any order but it is
recommended that the larger DIMM is install in Slot 0.
For more information, visit Techworks web site at www.techworks.com
(5) External interface block
• IEEE1284 Interface
• USB (Hi-Speed USB2.0)
• Ethernet (10/100Base TX)
