BTG ICEfx - ICEfx Cart

2-4 User Manual
2.1.9 Argon Gas Inlet
The gas supply line connects the argon gas supply from the argon gas cylinder to the argon gas
inlet. The argon inlet is a quick-connect connector.
2.2 ICEfx Cart
The optional ICEfx Cart provides a secure platform for the Console. The ICEfx Cart has four locking
wheels to ensure the cart does not move during a cryoablation procedure. An opening inside the cart
provides storage for up to four cryoablation needle boxes.
The cart has handles for easy movement and a hook for attaching an accessory bag.
1
2
3
4
Front View Rear View
Figure 2-3. ICEfx Cart
1
Storage Area
3
Handle
2
Locking Wheel
4
Accessory Bag Hook
