BTG ICEfx - Title Bar; Table 4-1. Title Bar; Screen 4-1. Title Bar

4-2 User Manual
4.3.2 Title Bar
The Title Bar contains the Options Menu, the argon remaining, and the Pressure Gauge / Gas
Indicator.
1
2 3
Screen 4-1. Title Bar
Table 4-1. Title Bar
# Control Description
1 Options Menu Pressing the Options Menu icon displays an expanded menu of
options. Reference Section 4.3.3 for descriptions of the available
options.
2 Argon Remaining Displays an estimate of time remaining before depletion of the
cylinder assuming that all connected needles are operated
simultaneously.
3 Pressure Gauge / Gas
Indicator
Displays the supplied pressure of the argon gas cylinder.
NOTE: The ICEfx System contains an internal regulator that
regulates the argon pressure to appropriate working limits.
The Gas Indicator updates in real-time as needles are
disconnected or additional needles are connected and as the
freeze intensity is adjusted.
