ICEfx™ Cryoablation System
4-11
4.6.4 Initiating a Freeze Cycle
To start a freeze cycle, press the Freeze button to select the desired freeze intensity (default is
100%), and then press the Start button. A freeze cycle can be initiated for a single active channel or
for ALL active channels simultaneously.
During freezing, the timer displays the elapsed time and the selected freeze intensity. For CX
needles, the needle tip temperature during freezing is displayed in the upper right corner of the timer.
3
1
4
2
Screen 4-9. Procedure Screen during Freezing
Table 4-9. Freeze Controls
# Control Description
1
Freeze button – Press to select the freeze function and to select the freeze
intensity.
