iv User Manual
List of Figures
Figure2-1.ConsoleFrontView 2-1
Figure2-2.ConsoleRearView 2-2
Figure 2-3. ICEfx Cart 2-4
Figure 2-4. ICEfx Cart - Wheel Lock Levers 2-5
Figure 3-1. Position ICEfx Console on Cart 3-2
Figure 3-2. Tighten Retaining Screw on Cart 3-2
Figure3-3.ArgonShuto󰀨Valve-ONPosition 3-3
Figure3-4.VentValve-FullyClosed 3-4
Figure 3-5. Attach Safety Cable to Console 3-6
Figure 3-6. Connect Argon Gas Supply Line 3-7
Figure 3-7. Gas Cylinder Set-up 3-7
Figure 3-8. Open Argon Gas Cylinder 3-8
Figure 3-9. EZ-Connect2 Dual Cylinder Adapter 3-9
Figure 5-1. Locking Needle into Channel 5-3
