Note
• The loading method for a printer with a Spectrophotometer Unit (option) is the same as for a printer with no Spectrophotome-
ter Unit (option). If it is difficult to perform operations from the front of the printer, lower the Up-down Unit. (See "Lowering the
Up-down Unit of the Spectrophotometer Unit (option) Manually.") âž” P.531
1
Press the Load button.
2
Press â–² or â–¼ to select Roll Paper, and then press the OK button.
Note
• If any paper has been advanced that will not be used, a message is shown requesting you to remove it.
Press â–² or â–¼ to select Yes, and then press the OK button. Remove the paper and go to the next step.
3
Open the Roll Feed Unit Cover.
4
Holding the Roll Holder flange (a), load the Roll Holder
shaft into the guide grooves (b) on both sides of the
Roll Holder Slot. At this time, load the shaft so that the
color of the Roll Holder shaft (c) matches the color of
the guide groove.
Caution
• Do not release the flanges until you load the holder fully in the Roll Holder Slot. Rolls are heavy, and dropping a roll
may cause injury.
• Be careful not to pinch your fingers between the guide grooves (b) and the Roll Holder shaft (c) when loading rolls.
Important
• Do not force the Roll Holder into the printer with the right and left ends reversed. Otherwise, it may damage the
printer or Roll Holder.
Loading Rolls in the Printer
iPF6400S
User's Guide
Handling and Use of Paper Handling rolls
510
