Canon imagePROGRAF iPF6400S - Carriage; Inside the Roll Feed Unit Cover

Inside the Roll Feed Unit Cover
Inside the Roll Feed Unit Cover
a
Roll Holder
Load the roll on this holder.
b Holder Stopper
Secure rolls on the Roll Holder with this part.
c
Roll Holder Slot
Slide the Roll Holder into this slot.
Carriage
Carriage
Inside the Roll Feed Unit Cover
iPF6400S
User's Guide
