Replace the Maintenance Cartridge
1
Open the box of the new Maintenance Cartridge and
remove the plastic bag and packaging material. Holding
the handles (a) on both sides, pull out the cartridge.
Important
•
Never touch the metal contacts (a). This may damage the
Maintenance Cartridge.
2
Remove the Ejection Guide.
Important
•
If the Spectrophotometer Eject Guide is lowered while the
optional Spectrophotometer Unit is mounted, open the
Spectrophotometer Unit Cover and lift up the central part
(near the blue label) of the Up-down Unit.
Lifting up the ends of the Up-down Unit may cause dam-
age.
