8
Hold the Ejection Guide on both sides by the near end.
Aligning the Ejection Guide with the guides (a), insert it
into the printer until it locks in place.
Note
• If you did not perform the operation in Access the menu for Maintenance Cartridge replacement, this is the end
of the procedure and you do not need to press the OK key in the next step.
•
If the Spectrophotometer Unit is mounted, grasp the blue han-
dles on the left and right sides of the Spectrophotometer Eject
Guide, align the protruding parts of the Spectrophotometer
Eject Guide (a) with the Spectrophotometer Unit guide (b), and
push it in until it clicks.
9
Press the OK button.
Replacing the Maintenance Cartridge
iPF6400S
User's Guide
Maintenance and Consumables Maintenance Cartridge
904
