12-39
Machine Settings
SYSTEM SETTINGS
3. SET IP ADD RANGE Sets whether to restrict the range of IP addresses.
OFF Disables restriction of IP address of computers.
ON Enables you to set which IP addresses can send data (print/fax
jobs) to the machine. You can select to permit or reject up to
eight ranges of IP addresses. Set each range of IP addresses by
entering an IP address in both <START IP ADDRESS> and <END
IP ADDRESS>.
1. IP ADDRESS 1
2. IP ADDRESS 2
3. IP ADDRESS 3
4. IP ADDRESS 4
5. IP ADDRESS 5
6. IP ADDRESS 6
7. IP ADDRESS 7
8. IP ADDRESS 8
9. IP ADDRESS 9
10. IP ADDRESS 10
–
–
–
–
–
–
–
–
–
–
4. DNS SETTINGS Sets the DNS server settings.
1. DNS SERVER SET Registers the DNS server address.
1. PRIM. DNS
SERVER
Registers the primary server address.
2. SECOND
DNS SERVER
Registers the secondary server address.
2. HOST/DOMAIN
NAME
Registers the host name and domain name of the DNS server.
1. HOST NAME Registers the host name of the DNS server.
2. DOMAIN
NAME
Registers the domain name of the DNS server.
3. DNS DYNAMIC
SET
Sets whether to use the DNS server dynamic update setting.
1. DNS DYNA.
UPDATE
Sets whether to use the DNS server dynamic update function.
OFF
ON
–
–
2. IPv6 SETTINGS Sets IPv6 Address settings. (See "Set the Machine for Network
Usage," in the Starter Guide.)
1. USE IPv6 Sets whether to use IPv6 networks.
OFF Only IPv4 is used.
ON Both IPv4 and IPv6 are used. A link local address is also
automatically set.
