9-ACCESSORIES

Donotoperatethehydraulicbreakerinwater.Doingso

willcauserustandsealdamage,resultingindamageto

thehydraulicsystemcomponents.

NH019923

Donotusethehydraulicbreakertomoveobjects.Theex-

cavatormightoverturnand/orthehydraulicbreakermay

bedamaged.

NH020024

Donotoperatethebreakertothesideofthemachine.

Themachinemaybecomeunstableandundercarriage

componentslifemaybereduced.

NH020125

Operatetheexcavatorcarefullytoavoidhittingtheboom

withthehydraulicbreaker.

NH020226

9-18
