9-ACCESSORIES

Donotoperatethebreakerwiththearmpositionedverti-

cally.Excessivevibrationtothearmcylindermaycause

oilleakage.

NH020327

Pressthebreakersothatthechiselpointthrustissquare

(perpendicular)totheobjecttobebroken.

NH020428

Donotoperatethehydraulicbreakercontinuouslylonger

than20s.Excessivechiselwearwillresult.Ifanobject

couldnotbebrokenwithin20s,applychiseltootherlo-

cations,lessthan20sforeachlocation.

NH020529

9-19
