23. Removal of left-front door harness butt joint 1.
23.1. Disassemble the left A-pillar inner shield, and push down the
plastic lock that fixed the connector of the left-front door harness
butt joint 1. (See Removal of A-pillar inner shield )
23.2. Unplug the plug of the left-front door harness butt joint 1.
24. Removal of the left-front door harness butt joint 2.
24.1. Disassemble the left A-pillar inner shield, push down the
plastic lock that fixes the connector of left-front door harness butt
joint 2. (See Removal of A-pillar Inner Shield)
24.2. Unplug the plug of left-front door harness butt joint 2.
25. Removal of interior and right-front door butt joint 1.
25.1. Disassemble the right A-pillar inner shield, and push down the
plastic lock that fixes the right-front door harness butt joint 2. (See
Removal of A-pillar Inner Shield)
25.2. Unplug the plug of right-front Door harness butt joint 1.
