Chroma 11210 - Page 127

SCPI Command
10-11
<NR1> Measurement Condition ID, in decimal format, ID definition as follows
W
hen measuring under IR mode and PD Tester function is disabled.
<NR3> DUT Test Voltage, unit: V
<NR3> IR Test Result, unit: Ohm
<NR3> Reserved
<NR1> Measurement Condition ID, in decimal format, ID definition as follows.
W
hen measuring under LC mode and PD Tester function is enabled.
<NR3> DUT Test Voltage, unit: V
<NR3> LC Test Result, unit: mA
<NR3> Reserved
<NR1> PDV Level, unit: None
<NR1> PDV Times, unit: Times
<NR1> PDI Level, unit: None
<NR1> PDI Times, unit: Times
<NR1> Measurement Condition ID, in decimal format, ID definition as follows
When measuring under IR mode and PD Tester function is enabled.
<NR3> DUT Test Voltage, unit: V
<NR3> IR Test Result, unit: Ohm
<NR3> Reserved
<NR1> PDV Level, unit: None
<NR1> PDV Times, unit: Times
<NR1> PDI Level. Unit: None
<NR1> PDI Times, Unit: Times
<NR1> Measurement Condition ID, in decimal format, ID definition as follows
Measurement
Condition
Condition ID
Measurement
Condition
Condition ID
Total PASS
0
/Discharge Fail
1
Charge Fail
2
Contact Check Fail
3
LC Low / IR High
4
LC High / IR Low
5
LC Over Range
6
Auto Range Fail
7
PD Fail
8
Trigger Stop
9
LCTest:MEASure:IR?
It queries insulation resistance value of LC measurement result currently.
Set command format: LCTest:MEASure:IR?
Parameter: None
Return data: <NR2>, the unit: Ohm
LCTest:MEASure:LC?
It queries leakage current value of LC measurement result currently.
Set command format: LCTest:MEASure:LC?
Parameter: None
Return data: <NR2>, the unit: mA
LCTest:MEASure:VMEAS?
It queries DUT maximum voltage of LC measurement result currently.
Set command format: LCTest:MEASure:VMEAS?
Parameter: None
Return data: <NR2>, the unit: V
