SCPI Command
10-13
Parameter: <NRf>, the range is 0~9.999, unit: S. MIN and MAX are acceptable.
Return data: <NR2> the unit is S.
WVTest:CONFigure:TIME:DWELL
It sets or queries dwell time during measurement.
Set command format: WVTest:CONFigure:TIME:DWELL {<NRf>|MIN|MAX}
Parameter: <NRF>, the range is 0.005 ~ 99.999s.
MAX: 99.999s and MIN: 0.005s are acceptable.
Return data: <NRF> the unit is S.
WVTest:CONFigure:TIME:TEST
It sets or queries the test time during measurement.
Set command format: WVTest:CONFigure:TIME:TEST {<NRf>|MIN|MAX}
Parameter: <NRF>, the range is 0.005 ~ 99.999s.
MAX:99.999s and MIN:0.005s are acceptable.
Return data: <NRF> the unit is S.
WVTest:CONFigure?
It queries all parameters of measurement function.
Set command format: WVTest:CONFigure?
Parameter: None
Return data: There are 9 parameters, WV Voltage Limit , WV Charge Current,
Trigger Mode, Integration Time, Customize Integration Time, Dwell
Time, Test Time, and Contact Check Enable. Refer to each command
for its return format.
WVTest:MEASure:STATe?
It queries the measurement status at present.
Set command format: WVTest:MEASure:STATe?
Parameter: None
Return data: IDLE, CHG, DWELL and TEST
WVTest:MEASure:FETCh?
It queries the measured result during measurement.
Set command format: WVTest:MEASure:FETCh?
Parameter: None
Return data:
<NR3> DUT Test Voltage, unit: V
<NR3> Reserved
<NR1> Measurement Condition ID, in decimal format, ID definition as follows:
Measurement
Condition
Condition ID
Measurement
Condition
Condition ID
Total PASS
0
/Discharge Fail
1
Voltage Limit Fail
6
Trigger Stop
9
WVTest:MEASure:VMEAS?
It queries the DUT highest voltage of LC measured result.
Set command format: WVTest:MEASure:VMEAS?
Parameter: None
Return data: <NR2>, unit: V
